Emulex LPe31000/LPe32000 Fibre Channel HBA Adapter Test

Emulex is a leading enterprise server and storage solution provider, specializing in converged networking systems. Its products include HBA adapters, intelligent storage platforms, storage switches, routers, bridges and I/O controllers, widely adopted by mainstream global server and storage OEMs. Founded in 1978, Emulex is headquartered in California, USA.

Moduletek Laboratory purchased Emulex LPe31002-M6 and LPe32002-M2 Fibre Channel adapters, supporting compatibility testing of 4G/8G/16G/32G FC rates. The installation and verification test process is as follows.

Figure 1 Device Official Description

LPe31002-M6: 16G dual-port FC adapter, compatible with 4G / 8G / 16G rates.

LPe32002-M2: 32G dual-port FC adapter, compatible with 8G / 16G / 32G rates.

Table 1 Physical Display of Network Cards

Model	Physical Image
LPe31002-M6
LPe32002-M2

1. Network Card On-Server Identification Test

Install LPe31002-M6 and LPe32002-M2 adapters into Dell server, then View adapter hardware recognition information under CentOS Linux system.

Table 2 On-Server Identification of Network Cards

LPe31002-M6	LPe32002-M2

2. Network Card & Optical Transceiver Identification Test

• Match LPe31002-M6 with original Emulex AFBR-57F5MZ-ELX 16G SW transceiver to Query port rate and link status.

• Match LPe32002-M2 with original Emulex FTLF8532P4BCV-EM 32G SW transceiver to Check port rate and link status.

Table 3 NIC Optical Module Identification

LPe31002-M6_AFBR-57F5MZ-ELX	LPe32002-M2_FTLF8532P4BCV-EM

Moduletek 16G & 32G Fibre Channel transceivers are fully compatible with Emulex adapters. Welcome to inquire and purchase.

For further inquiries about the above content, please contact us at: sales@moduletek.com
